Products > PCL > Nitrogen generator cum inflator
Product Details
PCL-Sumo Nitrogen product provides cost effective and flexible revenue generating opportunities for tyre service provides offering high levels of N2 performance, low running costs and long lifetime, all for a moderate capital outlay.
The N2 Generator from PCL Sumo brings the latest in PSA (Pressure Swing Adsorption) process for Nitrogen Generation to a robust, cost effective and mobile design capable of delivering high levels of N2 purity.
This equipment incorporates the ability to preset the tyre pressure allowing the Operator to automatically inflate four car tyres simultaneously with air or nitrogen to the required level, thus saving time and money.
Using a proprietary software, specially developed for N2 Inflation, the unit converts air to nitrogen in up to four tyres at once with the bespoke software and adjustable purge cycles (settable from 1 to 5), allowing the delivery of consistent high levels of N2 purity in the tyre where it is really needed. The unit incorporates an air and Nitrogen selector so this can act as both an Air Tower where required and at the same time offering at the flick of a lever, the full capability of very efficient high purity and low cost N2 delivery.
To know the benefits of using Nitrogen, please check our detailed explaination on the learning center. <Link>
The N2 Generator from PCL Sumo brings the latest in PSA (Pressure Swing Adsorption) process for Nitrogen Generation to a robust, cost effective and mobile design capable of delivering high levels of N2 purity.
This equipment incorporates the ability to preset the tyre pressure allowing the Operator to automatically inflate four car tyres simultaneously with air or nitrogen to the required level, thus saving time and money.
Using a proprietary software, specially developed for N2 Inflation, the unit converts air to nitrogen in up to four tyres at once with the bespoke software and adjustable purge cycles (settable from 1 to 5), allowing the delivery of consistent high levels of N2 purity in the tyre where it is really needed. The unit incorporates an air and Nitrogen selector so this can act as both an Air Tower where required and at the same time offering at the flick of a lever, the full capability of very efficient high purity and low cost N2 delivery.
To know the benefits of using Nitrogen, please check our detailed explaination on the learning center. <Link>
- Model No.: N2A- 4000/70
- Power Supply: Stabilized AC 240V/ 50 Hz
- Power Consumption: Max- 20VA
- Production Capacity: 4000 liters per hour (LPH)
- Inlet Air Pressure: 10 bar (~ 150 PSI)
- Outlet N2 Pressure: 8 bar (~120 PSI)
- N2 purity: 95-99.5%
- N2 Tank Capacity: 70 Liters
- Powder Coated Cabinet: Size 600 x 510 x 1400 mm
- Pressure Measurement Accuracy: +/-0.5% of FSR (Full Scale
Reading)
- High Pressure Rubber Braided Hose:One No. Supplied, 7.5 Meters
long fitted with heavy duty euro clip-on connector and quick release
coupling adapter.
- Proprietary Software for optimal N2 inflation for up to 4 tyres.
- High quality prefilteration with inbuilt activated carbon filter.
- Power Supply: Stabilized AC 240V/ 50 Hz
- Power Consumption: Max- 20VA
- Production Capacity: 4000 liters per hour (LPH)
- Inlet Air Pressure: 10 bar (~ 150 PSI)
- Outlet N2 Pressure: 8 bar (~120 PSI)
- N2 purity: 95-99.5%
- N2 Tank Capacity: 70 Liters
- Powder Coated Cabinet: Size 600 x 510 x 1400 mm
- Pressure Measurement Accuracy: +/-0.5% of FSR (Full Scale
Reading)
- High Pressure Rubber Braided Hose:One No. Supplied, 7.5 Meters
long fitted with heavy duty euro clip-on connector and quick release
coupling adapter.
- Proprietary Software for optimal N2 inflation for up to 4 tyres.
- High quality prefilteration with inbuilt activated carbon filter.
- High performance imported grade CMS
(Carbon Molecular -sieves) from Germany for longer trouble free life.
- Specially designed high volume CMS towers for continuous supply of
pure N2 at higher flow rate.
- In built provision of simultaneous four tyres inflation / deflation.
- Low life time costs- with high grade filtration including activated
carbon and high performance components.
- N2 purity Check point provided
(Carbon Molecular -sieves) from Germany for longer trouble free life.
- Specially designed high volume CMS towers for continuous supply of
pure N2 at higher flow rate.
- In built provision of simultaneous four tyres inflation / deflation.
- Low life time costs- with high grade filtration including activated
carbon and high performance components.
- N2 purity Check point provided
